Sapphire Pulse Radeon RX 7800 XT 16GB

Sapphire Pulse Radeon RX 7800 XT 16GB At Best Price

The Sapphire Pulse Radeon RX 7800 XT 16GB is a high-performance graphics card that is part of AMD's new Radeon RX 7000 series. It is based on the RDNA 3 architecture and features 16GB of GDDR6 memory. The card has a boost clock of up to 2430 MHz and supports DirectX 12 Ultimate.

Features

Digital Power Design

SAPPHIRE PULSE AMD Radeon™ RX 7800 Series is designed with digital power which provides accurate power control and excellent power efficiency

Ultra High-Performance Conductive Polymer Aluminum Capacitor

The Ultra High-Performance Conductive Polymer Aluminum Capacitor has a small PCB footprint but high volumetric capacitance that makes 14-phase power possible on the RX 7800 series graphics card. The capacitor offers stable capacitance at a high frequency and temperature with very low signal noise, ensuring the stability and reliability of the product.

High TG Copper PCB

The GPU is mounted onto the high-density 14-layer 2oz Copper and high TG PCB to match the rapid speed, high current, and increased power requirement of the GPU and memory to guarantee high stability of the PCB during operation.

Angular Velocity Fan Blade

The Angular Velocity Fan Blade provides a double layer of downward air pressure which alongside the air pressure on the outer ring of the Axial fan, results in up to 44% more downward air pressure and up to 19% more airflow for a quieter and cooler operation when compared to the previous generations.

Optimized Composite Heatpipe

The composite heat pipes are fine-tuned for each cooling design with optimal heat flow, efficiently and evenly spreading out the heat to the entire cooling module.

Fuse Protection

To protect your card, the SAPPHIRE cards have fuse protection built into the circuit of the external PCI-E power connector to keep the components safe.

Two-Ball Bearing

These feature Dual Ball bearing fans, which have an approximately 85% longer lifespan than sleeve bearings in our tests. The improvements to the fan blades mean the solution is up to 10% quieter than the previous generation.

We recommend a Power Supply of 700W for this graphics card. Please check our selected collections

Click Here

Specifications

MODEL11330-02-20G

CHIPSETAMD RADEON

GPURX 7800 XT

PCI EXPRESS4.0

MEMORY SIZE16 GB

MEMORY INTERFACE256-BIT

MEMORY TYPEGDDR6

DIRECT X SUPPORT12 Ultimate

OPEN GL4.6

PORTS

• 2x HDMI
• 2x DisplayPort

RESOLUTION7680 x 4320

COOLERDual-Fan

SOFTWAREDriver & Software

PACKAGE CONTENTSGraphics Card, User Manual

POWER CONNECTORS2 x 8-pin

WARRANTY3 Years
