MSI MPG Z590 Gaming Edge WIFI Motherboard

MSI MPG Z590 Gaming Edge WIFI Motherboard
Out Of Stock

The MSI MPG Series Z590 Gaming Edge WiFi is an ATX Motherboard, Featuring DDR4 5333 MHz Memory Support, 16 Phase Digital VRM, 6 Layer PCB, Intel WiFi 6E, 2.5 Gigabit Ethernet And Realtek ALC4080 Premium Audio.

Features

MPG Z590 GAMING EDGE WIFI

  • Supports 11th and 10th Gen Intel® Core™ / Pentium® Celeron® processors for LGA 1200 socket
  • Supports DDR4 Memory, up to 5333(OC) MHz
  • Lightning Fast Game experience: PCIe 4.0, Lightning Gen 4 x4 M.2, USB 3.2 Gen 2x2
  • Enhanced Power Design: 14+1+1 Duet Rail Power System, dual 8-pin CPU power connectors, Core Boost, DDR4 Boost
  • Premium Thermal Solution: Enlarged heatsink with heat-pipe, MOSFET thermal pads rated for 7W/mk, additional choke thermal pads and 3x M.2 Shield Frozr are built for high performance system and non-stop gaming experience
  • MYSTIC LIGHT: 16.8 million colors / 29 effects controlled in one click. MYSTIC LIGHT EXTENSION supports both RGB and RAINBOW LED strip.
  • 2.5G LAN with LAN Manager and Intel Wi-Fi 6E Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection
  • AUDIO BOOST 5: Reward your ears with studio grade sound quality for the most immersive gaming experience
  • High Quality PCB: 6-layer PCB made by 2oz thickened copper and server grade level material
  • Pre-installed I/O Shield: Better EMI protection and more convenience for installation

Specifications:


  • PROCESSOR

Supports 10th Gen Intel® Core™ Processors, 11th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors 1

Processor socket LGA1200

  • CHIPSET

Intel® Z590 Chipset

  • MEMORY

4x DDR4 memory slots, support up to 128GB

Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel® CPU (by JEDEC & POR)

Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen Intel® CPU (by JEDEC & POR)

Max overclocking frequency:

1DPC 1R Max speed up to 5333 MHz

1DPC 2R Max speed up to 4700+ MHz

2DPC 1R Max speed up to 4400+ MHz

2DPC 2R Max speed up to 4000+ MHz

Supports Dual-Channel mode

Supports non-ECC, un-buffered memory

Supports Intel® Extreme Memory Profile (XMP)

  • EXPANSION SLOTS

3x PCIe x16 slots

Support x16/x4/x4

PCI_E1 (From CPU)

Supports up to PCIe 4.0 for 11th Gen Intel® CPU

Supports up to PCIe 3.0 for 10th Gen Intel® CPU

PCI_E3 & PCI_E5 (From Z590 Chipset)

Support up to PCIe 3.0

2x PCIe 3.0 x1 slots (From Z590 Chipset)

ONBOARD GRAPHICS

1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz

1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz

MULTI-GPU Supports AMD® CrossFire™ Technology

  • STORAGE

6x SATA 6Gb/s ports (From Z590 Chipset)

3x M.2 slots (Key M)

M2_1 slot (From CPU)

Available only on 11th Gen Intel® CPU

Supports PCIe 4.0 x4

Supports 2242/ 2260/ 2280/ 22110 storage devices

M2_2 & M2_3 slot (From Z590 Chipset)

Support up to PCIe 3.0 x4 and SATA 6Gb/s

Supports 2242/ 2260/ 2280 storage devices

Intel® Optane™ Memory Ready

Supports Intel® Smart Response Technology for Intel® Core™ processors

PCI_E3 will be unavailable when installing M.2 SSD in the M2_2 slot. SATA2 will be unavailable when installing M.2 SATA SSD in the M2_2 slot.

SATA5 & SATA6 will be unavailable when installing M.2 SSD in the M2_3 slot.

Before using Intel® Optane™ memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website.

  • RAID

Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices

Supports RAID 0, RAID 1 and RAID 5 for M.2 PCIe storage devices

  • USB

Intel® Z590 Chipset


1x USB3.2 Gen2x2 20Gbps port (Type-C port on the back panel)

4x USB 3.2 Gen 1 5Gbps ports (2 Type-A port on the back panel and 2 ports are available through the internal connectors)

4x USB 3.2 Gen 2 10Gbps ports (1 Type-C internal connector and 3 Type-A ports on the back panel)

Hub-GL850GMSI MPG Z590 GAMING EDGE WIFI


6x USB 2.0 ports (2 Type-A port on the back panel and 4 ports are available through the internal connectors)

  • AUDIO

Realtek® ALC4080 Codec

7.1-Channel High Definition Audio

Supports S/PDIF output

  • LAN

1x Intel® I225V 2.5Gbps LAN controller

  • WIFI & BLUETOOTH

Intel® Wi-Fi 6E AX210

The Wireless module is pre-installed in the M.2 (Key-E) slot

Supports MU-MIMO TX/RX, 2.4GHz/ 6GHz (160MHz) up to 2.4Gbps

Supports 802.11 a/ b/ g/ n/ ac/ ax

Supports Bluetooth 5.2, FIPS, FISMA

Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in WIN10 21H1.

Bluetooth 5.2 will be ready in WIN10 21H1

  • INTERNAL CONNECTORS

1x 24-pin ATX main power connector

2x 8-pin ATX 12V power connectors

1x 6-pin PCIE power connector

6x SATA 6Gb/s connectors

3x M.2 slots (M-Key)

1x USB 3.2 Gen 2 10Gbps Type-C port

1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports)

2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)

1x 4-pin CPU fan connector

1x 4-pin water-pump fan connector

6x 4-pin system fan connectors

1x Front panel audio connector

2x System panel connectors

1x Chassis Intrusion connector

1x Clear CMOS jumper

1x TPM module connector

1x TBT connector (supports RTD3)

  • LED FEATURE

2x 4-pin RGB LED connectors

2x 3-pin RAINBOW LED connectors

1x EZ LED Control switch

4x EZ Debug LED

  • BACK PANEL PORTS

DisplayPort

USB 3.2 Gen 1 5Gbps Type-A

2.5G LAN

Wi-Fi/Bluetooth

Audio Connectors

Flash BIOS Button

USB 2.0

HDMI

USB 3.2 Gen 2 10Gbps Type-A

USB 3.2 Gen 2x2 20Gbps Type-C

Optical S/PDIF Out

  • DIMENSIONS

ATX Form Factor

12 in. x 9.6 in. (30.5 cm x 24.4 cm)

  • MOUNTING-

9 mounting holes

  • OPERATING SYSTEM-

Support for Windows® 10 64-bit

  • Warranty-

3 Years
