Gaming is in the core of the new MasterBox K501L ARGB. Donning an illuminated fan against the angled front panel ventilation speaks to its competitive character. Support of gaming hardware like long graphics cards, plenty of storage, and liquid cooling take priority in the K501L ARGB while still leaving room for future upgrades.
Compatibility for high-performance hardware makes the K501L ARGB the essential start in building a monster rig, competitively priced to point the focus toward upgrades.
- Angled Ventilation – The aggressive, angled front panel ventilation dons sharp design elements and striking lines, signifying the K501L’s competitive character.
- Illuminated Fan & Power Button – Paired with lighting on the power button, an illuminated fan glows through the angled ventilation; a testament to its gamer core.
- Top Panel Ventilation – For increased thermal performance, the top panel is ventilated to support cooling components and filtered to protect against dust.
- Versatile Cooling Support
Support for up to seven 120mm fans and 360mm front and top radiator support ensure that performance is not compromised.
- Dual 360mm Radiator Support
For enthusiast-grade cooling, two 360mm radiators are supported on the top and front panel to keep the most extreme systems cool.
- Edge-to-Edge Tempered Glass Side Panel – Showcase your build through the 4mm tempered glass side panel.
- Versatile Component Support – Clearances of 410mm for the graphics card, 165mm for CPU coolers, and 200mm for PSUs offer room for powerful builds and future upgrades.
Model Number- MCB-K501L-KGNN-SR3
Materials- Steel, Plastic, Tempered Glass
Dimensions- 496mm x 217mm x 469mm (incl. Protrusions), 428.7mm x 205mm x 458.5mm (excl. Protrusions)
Motherboard Support- Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*support for up to 12" x 10.7", will limit cable management features)
Expansion Slots- 7
5.25" Drive Bays- 0
2.5" / 3.5" Drive Bays (combo)- 2
2.5" Drive Bays- 4 (2+2 combo)
I/O Panel- 1x USB 3.0 Type-A, 1x USB 2.0, 1x 3.5mm Audio Jack, 1x 3.5mm Mic Jack
Pre-installed Fans - Top N/A
Pre-installed Fans - Front 2x 120mm ARGB Fan
Pre-installed Fans - Rear 1x 120mm
Fan Support - Top- 3x 120mm, 2x 140mm
Fan Support - Front- 3x 120mm, 2x 140mm
Fan Support - Rear- 1x 120mm
Fan Support - Bottom- N/A
Radiator Support - Top- 120mm, 240mm, 360mm, (44mm max motherboard component height)
Radiator Support - Front- 120mm, 140mm, 240mm, 280mm, 360mm
Radiator Support - Rear- 120mm
Clearance - CPU Cooler- 165mm/6.49"
Clearance - PSU- 180mm/7.08", 295mm/11.61" (w/ HDD cage removed)
Clearance - GFX- 410mm/16.1"
Cable Routing- 19mm/0.74"
Dust Filters- Top, Front, Bottom
Power Supply Support- Bottom mount, ATX
Warranty- 2 Years
